FZH Bin Blender features steady running, stable structure, large
capacity and high mixing evenness. It is the ideal in pharmaceutical factory for final blending. And it is also widely
used in food and chemical industry. The Square Cone mixer is mainly
used in blending dry powders or graules.
It is steady in transmission, reliable in structure fully capable
and highly uniform in mixing.
Features of Square cone blender:
With novel design, compact structure and beautiful appearance, the
machine can reach mixing evenness of 99% and volume loading
coefficient of 0.8. It has such features as high rotation height,
stable running, reliable performance and convenient operation. The
inner and outer walls of the barrel are subject to mirror polishing
with easy discharging and easy cleaning and without any dead
corners and cross contamination, meeting GMP requirements.
1, Inner wall of the hopper is slippry easy to clean and his no
dead angles.
2, Make dst-free enviromen for production with GMP requirements.
3, Mixing uniform up to 99%
4, Work with Inverter to control the speed, and will be more stable
and without vibration.
5, Working parameters like mixing time and rotating speed can be
set.
6, Feeding valve is equiped with anni-misoperation device, easy to
be removed and cleaned.
Technical parameters
| Model | Rotary speed (rpm) | L | Max. loading volume (L) | Max. loading capacity (Kg) | Total power (Kw) | Weight (Kg) |
| FZH-400 | 3-20 | 400 | 320 | 200 | 2.2 | 600 |
| FZH-600 | 3-20 | 600 | 480 | 300 | 3 | 700 |
| FZH-800 | 3-20 | 800 | 640 | 400 | 3 | 800 |
| FZH-1000 | 3-15 | 1000 | 800 | 500 | 4 | 1000 |
| FZH-1200 | 3-15 | 1200 | 960 | 600 | 4 | 1200 |
| FZH-1500 | 3-15 | 1500 | 1200 | 750 | 5.5 | 1500 |
| FZH-2000 | 3-15 | 2000 | 1600 | 1000 | 5.5 | 2000 |
| FZH-3000 | 2-10 | 3000 | 2400 | 1500 | 7.5 | 2900 |
| FZH-4000 | 2-10 | 4000 | 3200 | 2000 | 11 | 3500 |
| FZH-5000 | 3-8 | 5000 | 4000 | 2500 | 11 | 4000 |
| FZH-6000 | 3-8 | 6000 | 4800 | 3000 | 11 | 5200 |
| FZH-8000 | 1-6 | 8000 | 6400 | 4000 | 15 | 6300 |
| FZH-10000 | 1-6 | 10000 | 8000 | 5000 | 15 | 7500 |
Part of Certifications:
Part of Exhibitions:
Our Factory:
Q1. Why choose us?
A. We have rich experience in pharmaceutical machinery. We have
imported technologies from our US partners and the American
Engineering team always comes to and stays in our factory
frequently to guide the production and do R&D job together with
Chinese Engineering team.
Q2. May I have your customer list?
A. Sure, you can contact with our seller ask for it. Our customers
were all pleased with our machine and service.
Q3. What's the guarantee period?
A. The warranty period is within 12 months from the date of
acceptance but not longer than 15 months from the date of Bill of
Lading.
Q4. Will you send technicians for installation and commissioning?
A. Yes, we will assign our engineering staffs to guide the
installation and adjustment. But the customers shall cover some
fees.
Q5. Could you give me some advice of the Medicine production?
A. Sure, we can give you some professional advice from our
experience. It's our pleasure to help.
