| type | 3 | 5 | 30 | 60 | 120 | 200 | 300 | 500 | 1000 |
| item | unit |
Container of raw material | diameter | mm | 300 | 400 | 700 | 1000 | 1200 | 1400 | 1600 | 1800 | 2200 |
| volume | L | 12 | 22 | 100 | 220 | 420 | 670 | 1000 | 1500 | 2500 |
Production capacity | min | kg/batch | 1.5 | 4 | 15 | 30 | 80 | 100 | 150 | 250 | 500 |
| max | kg/batch | 4 | 6 | 36 | 72 | 140 | 240 | 360 | 600 | 1100 |
| consumption of steam | kg/h | 12 | 23 | 70 | 140 | 211 | 282 | 366 | 465 | 800 |
amount of compressed air | m3/min | 0.3 | 0.3 | 0.3 | 0.6 | 0.6 | 0.9 | 0.9 | 0.9 | 1.5 |
| Power of fan | kw | 2.2 | 4 | 5.5 | 11 | 18.5 | 22 | 30 | 45 | 75 |
| Temperature | ºC | 120°C (Adjustable from ambient to 120) |
| Yield | % | >99 |
| Option time | min | 1530(depends on material) |
| Content at final term. | % | -0.2( depends on material) |
| Noise | dB | ≤75 |
| Height of main machine | mm | 2100 | 2300 | 2500 | 3000 | 3300 | 3800 | 4000 | 4800 | 6200 |
Working Principle
The process consists of two programs including mixing and
granulating process.
Powder material can be charged into the material pan from the
conical hopper and continue to rotate in the container under the
action of mixing blade once the hopper is closed. In the meanwhile,
all materials grow up the shape of liquid bridge under continuous
effects of conical wall. Under the action of extrusion, friction as
well as crumb by blade and conical tank wall, all material is
gradually turned to loosen. At last, while opening the hopper
outlet, waterish particles are pushed off under the centrifugal
effects blade.
Application
1. Drugs granulation and coating.
2. Granulation: Tablet particles, granule particles, capsule
particles.
3. Coating: particles, pill covers, color-prepared, slow-release,
films, enteric coating.
4. Food granulation and coating Granulated sugar, coffee, cacao
powder, cream, juice powder, amino acids, sauce, puffed food.
5. Pesticide, paint pigment, dry granulation Powder, granules,
block materials.
